Mineduino

Mineduino offers you the connection between redstone to real world electronic, or websites.
It allow bidirectional communication over MQTT

Docs:
https://docs.mineduino.com

It supports all redstone output devices (lever, pressure plates, relays, redstone wires) as sender to MQTT topics.
It supports actually 4 input types:
- raw
- simple
- hidden
- sign

1. In order to create raw input:
- Put iron block on anvil and name it as: MD/IDENTIFIER/raw,
where identifier is your unique name
- Put the iron block on the world

From now the MQTT topic MD/IDENTIFIER/raw is accepting data.
If data will contain 1 -> it will turn iron block to redstone block
If data will contain 0 -> it will turn redstone block back to iron block

2. In order to create simple input:
- Put chest block on anvil and name it as: MD/IDENTIFIER/simple,
where identifier is your unique name
- Put the chest on the world

From now the MQTT topic MD/IDENTIFIER/simple is accepting data from 0-27
If data will be 3 -> it will put 3 wooden hoes into chest
If data will be N -> it will try to put N wooden hoes into chest
You can measure fill of chest via comparator.

3. In order to create hidden input:
- Put stone on anvil and name it as: MD/IDENTIFIER/hidden,
where identifier is your unique name
- Put the stone on the world

From now the MQTT topic MD/IDENTIFIER/simple is accepting data.
If data will be 0 -> it will unhide stone
If data will be 1 -> it will hide stone

4. In order to create sign input:
- Put sign on anvil and name it as: MD/IDENTIFIER/sign,
where identifier is your unique name
- Put the sign on the world

From now the MQTT topic MD/IDENTIFIER/sign is accepting data in json array format:
["line1", "line2", "line3", "line4"]

When you will send this to the MD/IDENTIFIER/sign it will show these lines on sign!
It also support color codes

5. In order to create smart output:
- Put chest on anvil and name it as: MD/IDENTIFIER/smart,
where identifier is your unique name
- Put the chest on the world

Every 5 seconds it will publish it's content!

Works on 1.15.1 also

Showcase of 1.0-alpha version:

Example project:
